Autoterm Planar 9D Diesel Air Heater - Universal 8KW Kit

The Autoterm Planar Deisel Air Heaters are manufactured by the Latvian Manufacturer ADVERS and in Europe they are distributed through Autoterm. All of our products then come through their UK distributor Planar Heaters UK. These should not be confused with some of the Chinese imports you may see that are using the generic Planar name.



Autoterm Air 9D 8kW

Autoterm water and air heaters are built to ISO 9001-2015 standards. They also have E2 R10 and E2 R122 approval for whole vehicle approval for use in road

vehicles.

 Autoterm Air 9D 8kW is a compact heater model produced by heating experts Autoterm. This heating system can be used in crew cabins and work spaces of motorhomes, commercial vans and trucks as well as boats that are up to 48 feet long.



The kit comes with the PU-05 control panel as standard however you can upgrade to the new comfort controller.

Optional Upgrade - Comfort Control

• Intuitive user interface;
• LED status display.
• Thermostat function;
• Additional heating options;
• Quick access button for heating;
• Vehicle battery safety function;
• Heater maintenance reminder.
• Precise integrated digital temperature sensor.

Whats in the box:

• your choice of control panel
• silencer air intake
• fuel pump with mounting bracket
• 600mm of exhaust
• 1 fuel dip fuel tube and fuel line
• 1 power cable with integral fuse box
• 1 control panel cable
• 1 fuel pump power cable
• a selection of nuts and bolts.

The 8KW PLANAR 2D is the largest heater model in the production line, it is intended for use in buses, crew cabins and work spaces, commercial vans and trucks, as well as boats/yachts.

The capacity of the PLANAR 2D air heater is between 3.2 kW and 8 kW, and it is capable of heating up 290 m3 of air hourly. It maintains excellent economy and uses between 0.42 litres and 1 litre of diesel per hour. They are available in either 12 or 24v versions.

Planar diesel heaters have fast become synonymous with great quality and fantastic customer services, all at a fraction of the cost of their competitors.



Main Advantages of Autoterm Heaters

• They are capable of operating at very low temperatures.
• They use inductive (brushless) electric motors designed for uninterrupted operation for 12,000 hours.
• Low fuel consumption.
• Best quality diesel heater at a fraction of the price of other Air Diesel Heaters.
• The heaters have proved their excellent quality, working in aggressive environments, such as, marine environments.
• These heaters come with a 3 year guarantee and UK technical support if needed.
• After sales technical help and telephone support 7 days a week



Specification

Air heater PLANAR-9D-12-3910 12V/24V	Modes
Technical characteristics	High	Low
Heat power, kW	8	3.2
Fuel consumption, l/h	1.0	0.42
Rated power consumption, W	215(12v) 180 (24v)	12
Heated air volume, m3/h	290	70
Fuel	diesel fuel as per GOST 305
Rated voltage, V	12 or 24
Control mode	Manual, standard, 7 day electronic timer, or modem
Weight, kg	12.8
Heater dimensions	650 x 212 x 281 mm
